Description
32 Inch Universal Smart Android TV Motherboard N.H352.818
| Brand | ME |
| Part Number | N.H352.818 |
| Android Version | 12 |
| RAM | 2GB (Hardware 1GB) |
| ROM | 16GB |
| Type | Universal Android TV Board |
| Power Consumption | 50W |
| Supporting Resolution | HD(1366×768) and Full HD(1920×1080) |
| Backlight Output Voltage | 33v-94v |
| Performance | Outstanding |
| Miracast | Yes Available |
| Bluetooth | Not Available |
| Voice Remote | Not Support |
| Pack Type | COMBO Pack |
| Tuner | Not Available |
| Condition | NEW |
This is a Universal LED TV Android Combo Motherboard, which we will use to convert a normal LED TV into an Android LED TV. The performance is outstanding. We can use this motherboard for up to a 32-inch LED TV. But the LED backlight supports (32″) LED TV. If you install this motherboard below the 32″ LED TV you have to install an external backlight driver because this motherboard’s backlight output voltage is 33v – 94v which is too much for a small LED TV.
- Model: N.H352.818
- Supported Resolution: HD 1366×768 & 1920×1080 FHD
- Screen Format: 16:9
- RAM: 512 MB ROM: 8GB ROM
- Sound Output: 5Wx2
- Backlight Voltage: 64V to 94V
- Backlight Current: 200mA to 700 mA
- Backlight Power: 65W
- AC Input: 220V
- Service Menu Code: Source 815/Source 208/Source 2580
- Resolution Code: FHD SOURCE + 03661 & HD SOURCE + 03662
NOTE: If you are not a technician, do not try installing this board at home. If you install this board by yourself at your home and if you get any problem with the board, we do not provide any replacement and no refund we provide. To install the board go to the nearest TV repair shop and install it by an experienced technician.
