Description
DIGI VGL VGH Panel Booster Module
The DIGI VGL VGH Panel Booster Module is a professional-grade voltage correction and boosting board specially designed for LCD / LED TV panel repairing work.
This module helps restore and stabilize VGH (Gate High Voltage) and VGL (Gate Low Voltage) lines when they drop, fluctuate, or become missing due to panel circuit issues.
It is an essential tool for technicians who deal with:
- ✔️ No Display Problems
- ✔️ Half Screen Issues
- ✔️ Line Faults
- ✔️ Gate Driver IC Voltage Failures
- ✔️ Panel Gamma & Flicker Issues
If you are a technician working on LCD/LED panels, this module can save expensive panel replacement costs.
⚡ What is VGH & VGL? (Easy Explanation)
- 🔹 VGH (Gate High Voltage) → Usually +20V to +35V
- 🔹 VGL (Gate Low Voltage) → Usually -5V to -12V
These voltages control the Gate Driver ICs inside the panel.
If these voltages are weak or missing, the panel cannot operate properly.
👉 This booster module helps regenerate or stabilize these voltages.
🚀 Key Features
- ✅ Boosts and stabilizes VGH voltage
- ✅ Generates correct VGL negative voltage
- ✅ Compact & easy to install
- ✅ High efficiency voltage regulation
- ✅ Ideal for panel troubleshooting
- ✅ Reduces panel replacement cost
- ✅ Suitable for technician-level repairing
🛠️ Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | DIGI VGL VGH Panel Booster Module |
| Input Voltage | 5V – 12V DC |
| Output Voltage (VGH) | Adjustable +20V to +35V |
| Output Voltage (VGL) | Adjustable -5V to -12V |
| Application | LCD / LED TV Panel Repair |
| Installation Type | External Booster Module |
| Usage Level | Professional / Technician |
| PCB Type | High Quality Compact PCB |
🎯 Applications
This module is widely used in:
- 📺 LCD TV Panel Repair
- 📺 LED TV Panel Repair
- 🖥️ Monitor Panel Repair
- 🔧 T-Con Voltage Correction
- 🔧 Gate Driver Line Recovery
- 🛠️ Panel VGH/VGL Missing Voltage Fix
Perfect for workshops, service centers, and advanced technicians.
💡 Why Choose DIGI Panel Booster Module?
✔️ Saves expensive panel replacement
✔️ Quick solution for gate voltage problems
✔️ Easy testing & troubleshooting
✔️ Increases repair success rate
✔️ Compact and reliable design
If you repair LCD / LED TVs regularly, this is a must-have tool in your electronics toolkit.
⚠️ Important Note
- For professional use only
- Must be installed by a trained technician
- Always check panel short circuit before installation
- Use proper insulation while mounting
📦 Package Includes
-
1 × DIGI VGL VGH Panel Booster Module
