New Panel Booster Module for VGH and VGL Signal CB_V869K

Original price was: ₹599.00.Current price is: ₹499.00.

  • LCD Panel Booster
  • VGH VGL Signal Module
  • CB_V869K Booster
  • LED TV Signal Amplifier
  • LCD/LED Repair Module

Out of stock

Description

New Panel Booster Module for VGH and VGL Signal CB_V869K

The CB_V869K Panel Booster Module is an advanced solution designed to amplify and stabilize VGH (Voltage Gate High) and VGL (Voltage Gate Low) signals. This high-performance module ensures reliable operation in LCD and LED TV panel circuits, making it a vital component for repairing or enhancing display functionality.

Key Features

  1. Efficient Signal Boosting: Amplifies VGH and VGL signals to ensure stable display performance.
  2. Wide Compatibility: Supports various LCD and LED TV panels, including universal and branded models.
  3. Compact Design: Lightweight and small-sized module for easy installation in tight spaces.
  4. High Durability: Built with premium materials to ensure long-lasting performance.
  5. Low Power Consumption: Operates efficiently without drawing excessive power from the main circuit.
  6. Easy Installation: Pre-designed soldering points for hassle-free integration.

Technical Specifications

Parameter Details
Model Number CB_V869K
Input Voltage Range 9V – 20V
Output Voltage (VGH) Adjustable: +20V to +35V
Output Voltage (VGL) Adjustable: -5V to -12V
Compatibility LCD/LED Panels
Dimensions 40mm x 30mm x 5mm
Weight 15 grams

New Panel Booster Module for VGH and VGL Signal: CB_V869K


Product Description

The CB_V869K Panel Booster Module is an advanced solution designed to amplify and stabilize VGH (Voltage Gate High) and VGL (Voltage Gate Low) signals. This high-performance module ensures reliable operation in LCD and LED TV panel circuits, making it a vital component for repairing or enhancing display functionality.


Key Features

  1. Efficient Signal Boosting: Amplifies VGH and VGL signals to ensure stable display performance.
  2. Wide Compatibility: Supports various LCD and LED TV panels, including universal and branded models.
  3. Compact Design: Lightweight and small-sized module for easy installation in tight spaces.
  4. High Durability: Built with premium materials to ensure long-lasting performance.
  5. Low Power Consumption: Operates efficiently without drawing excessive power from the main circuit.
  6. Easy Installation: Pre-designed soldering points for hassle-free integration.

Technical Specifications

Parameter Details
Model Number CB_V869K
Input Voltage Range 9V – 20V
Output Voltage (VGH) Adjustable: +20V to +35V
Output Voltage (VGL) Adjustable: -5V to -12V
Compatibility LCD/LED Panels
Dimensions 6cm x 5cm x 2cm
Weight 20 grams

Applications

  • LCD/LED TV Repairing: Resolves issues like flickering, no display, or abnormal colour due to weak VGH/VGL signals.
  • Panel Replacement Projects: Enhances compatibility and performance of replacement panels.
  • DIY Electronics Projects: Suitable for hobbyists and technicians working on display modules.

How to Use

  1. Identify Panel Connections: Locate the VGH and VGL signal points on the LCD/LED TV panel.
  2. Connect Input Voltage: Supply power within the specified range to the module.
  3. Adjust Output Voltage: Use the adjustment points on the module to set the required VGH and VGL voltages.
  4. Solder Connections: Securely solder the module outputs to the panel circuit.
  5. Test Functionality: Power up the panel to ensure stable display performance.

This New Panel Booster Module for VGH and VGL Signal CB_V869K is a must-have tool for technicians and enthusiasts involved in LCD/LED TV repair and modification. It combines efficiency, versatility, and ease of use for a seamless experience.
