5L0380R SMPS PWM Module for Power Supply DELS-M1

(1 customer review)

Original price was: ₹120.00.Current price is: ₹89.00.

  • PWM Module
  • SMPS Module
  • Model No: DELS-M1
  • Power Supply Module
  • 5LO380R Module
  • Made By Dip Electronics LAB
  • Made In India Module
  • Work up to 65W SMPS
  • Ready to Use

Out of stock

Description

5L0380R SMPS PWM Module for Power Supply DELS-M1



this is an SMPS PWM Power supply module. Dip Electronics LAB makes this module for repairing and fixing power failures in any kind of SMPS which is working up to 65W. If you are an electronics technician, this module helps you a lot during the fix and repair of the power supply.

Connection Details

To install this module you have to connect 5 wires in SMPS. Before connecting those wires you need to remove the regulator IC and Switching MOSFET.

GND: This wire need to connect with the Main Finter capacitor Negative Point

D: D means drain point. You need to connect this point with the Switching MOSFET Drain point.

SP: SP means Starting Supply. You need to connect this wire with starting power supply capacitor Positive point.

300V: this wire you need to connect with the main finger capacitor Positive point.

FB: FB means feedback. this wire you need to connect with the Optocuplar 4 number pin.



Watch the video about How to make SMPS PWM Module by Dip Electronics LAB



Additional information

Weight 0.02 kg
Dimensions 4 × 4 × 3 cm
