HW-404 / XH-A232 Class D Audio Amplifier Board 30W + 30W Audio Output
Upgrade your DIY audio projects with the HW-404 / XH-A232 Class D Audio Amplifier Board, powered by the reliable TPA3110 amplifier chip. This compact yet powerful module delivers 30W + 30W stereo output, making it ideal for home audio systems, DIY speakers, car audio projects, and custom sound setups.
Designed with low idle power loss, high efficiency, and fast response performance, this board ensures clean, powerful, and distortion-free sound output.
⭐ Key Features
- 🔊 30W + 30W Stereo Output – Clear and powerful dual-channel sound
- ⚡ Wide Voltage Support (8V–26V DC) – Flexible power input options
- 🧠 TPA3110 Digital Power Amplifier Chip – High efficiency & low idle loss
- 🔥 Low Heat Generation – Class D efficiency reduces heating
- 🎵 Low Distortion Audio Output – Clean and crisp sound performance
- 📦 Compact & Lightweight Design – Easy to install in DIY enclosures
- 🛠️ Ready-to-Use Module – Simple wiring and fast integration
🧩 About TPA3110 Chip
The TPA3110 is a high-performance Class D digital power amplifier IC known for:
- ✔ Low idle power loss
- ✔ High efficiency (up to 90%)
- ✔ Fast working response
- ✔ Stable performance
- ✔ Reduced heat dissipation
It allows the board to deliver powerful sound while consuming less power.
📊 Technical Specifications
| Parameter | Details |
|---|---|
| Model | HW-404 / XH-A232 |
| Amplifier Type | Class D Digital Amplifier |
| Chipset | TPA3110 |
| Output Power | 30W + 30W (Stereo) |
| Supply Voltage | 8V – 26V DC |
| Recommended Voltage | 12V / 19V / 24V DC |
| Output Channels | 2 Channel (Stereo) |
| Efficiency | Up to 90% |
| Speaker Support | 4Ω – 8Ω Speakers |
| Audio Input | Analog Stereo Input |
| Heat Dissipation | Low (High Efficiency Design) |
🎯 Applications
This amplifier board is perfect for:
- 🔈 DIY Bluetooth Speaker Projects
- 🔊 Home Audio Amplifier System
- 🚗 Car Audio DIY Projects
- 📦 Portable Speaker Systems
- 🏫 School / Small Hall Audio Setup
- 🔧 Electronics Learning & Testing Projects
- 🎤 Small PA System
💡 Why Choose This Amplifier Board?
- High power in compact size
- Energy efficient Class D technology
- Wide voltage compatibility
- Reliable performance for long-term use
- Perfect for hobbyists & technicians
📦 Package Includes
-
1 × HW-404 / XH-A232 Class D Audio Amplifier Board
⚠ Important Notes
- Use proper DC power supply within 8V–26V range
- For full 30W + 30W output, use higher voltage (19V–24V) with proper cooling
- Ensure correct speaker impedance (4Ω–8Ω recommended)
