IGCM04G60HA Dual In-Line Intelligent Power Module (IPM) 4A 600V
The IGCM04G60HA Intelligent Power Module (IPM) is a high-performance 600V, 4A integrated power module designed for inverter-based applications. It combines IGBTs, gate drivers, and protection circuits in a compact dual in-line package, making it ideal for motor control and power switching systems.
This module helps reduce design complexity, improve reliability, and save PCB space — making it a smart choice for engineers, repair technicians, and electronics manufacturers.
⚡ Key Features & Highlights
- 🔹 Voltage Rating: 600V high-voltage capability
- 🔹 Current Rating: 4A output current
- 🔹 Built-in Gate Driver Circuit – No need for external driver IC
- 🔹 Integrated Protection Features – Overcurrent & undervoltage protection
- 🔹 Low Switching Loss – High efficiency performance
- 🔹 Compact Dual In-Line Package (DIP) – Easy PCB mounting
- 🔹 Optimized for Motor Drive Applications
- 🔹 Improved Thermal Performance
- 🔹 Reduced EMI Noise
📊 Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IGCM04G60HA |
| Module Type | Intelligent Power Module (IPM) |
| Package Type | Dual In-Line (DIP) |
| Rated Voltage | 600V |
| Rated Current | 4A |
| Power Device | IGBT |
| Control Type | Built-in Gate Driver |
| Protection Features | Overcurrent, Undervoltage Lockout |
| Application Type | Inverter & Motor Drive |
| Mounting Type | Through Hole |
🧠 What Makes This IPM Special?
✅ All-in-One Power Solution
This IPM integrates multiple components into a single module, reducing PCB design complexity.
✅ High Reliability
Built-in protection circuits prevent damage due to abnormal conditions.
✅ Perfect for Repair & Manufacturing
Suitable for replacing faulty inverter modules in home appliances and industrial equipment.
✅ Compact & Efficient
Saves board space while maintaining high performance.
🔧 Applications
This module is widely used in:
- 🌀 Air Conditioner Inverter Boards
- 🧺 Washing Machine Motor Drives
- 🏭 Industrial Motor Control Systems
- 🚗 Small Electric Vehicle Controllers
- ⚙️ Servo Motor Drives
- 🔌 UPS & Inverter Systems
- 🛠️ Electronics Repair Projects
🎯 Why Choose IGCM04G60HA?
✔ Reliable & durable
✔ Space-saving design
✔ Easy integration
✔ Ideal for inverter-based circuits
✔ Trusted for motor control applications
If you are a technician, engineer, or electronics enthusiast looking for a compact and intelligent power switching solution, the IGCM04G60HA is an excellent choice.
📦 Package Includes
-
1 × IGCM04G60HA Intelligent Power Module
