SP36821.5 42-inch Universal Android Motherboard
This is a Universal LED TV Android Combo Motherboard, which we will use to convert a Normal led tv into an Android LED Tv. The performance is outstanding. We can use this motherboard for up to a 43inch LED TV. But the LED backlight support (32″-43″) LED TV. If you install this motherboard below the 32″ LED TV you have to install an external backlight driver because this motherboard’s backlight output voltage is 64v – 94v which is too much for a small led tv.
Others All features of SP36821.5 Motherboard
- Model: SP36821.5
- Supported Resolution: HD 1366×768 & 1920×1080 FHD
- Screen Format: 16:9
- RAM: 1GbROM: 8Gb
- Sound Output: 5Wx2
- Backlight Voltage: 64V to 94V
- Backlight Current: 200mA to 700 mA
- Backlight Power: 65W
- AC Input: 220V
- Service Menu Code: Source 815/Source 208/Source 2580
- Resolution Code: FHD SOURCE + 03771 & HD SOURCE + 03772
